Audio Implements Model #655 Monitor Amplifier with Dialer and Microphone
See all Audio Implements items

Audio Implements Model #655 Monitor Amplifier with Dialer and Microphone

SKU: AI410 MFR: 410
Be the first to review this itemAsk a Question
$688.50
OR
$115/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Experience crystal-clear audio with this headphone amplifier's dual independent channels.
  • Connect seamlessly using the female XLR-3 connector for wet or dry input on this amplifier.
  • Monitor your audio with confidence, thanks to the 1/4" & 1/8" IFB outputs on this amplifier.
  • Enjoy versatile power options with a 9V battery or external AC adapter for this amplifier.
  • Rely on the durable die-cast aluminum build of this audio distribution amplifier for years.
  • Achieve optimal sound quality with the 8 ohms earphone output on this headphone amplifier.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$84.99

2 Year

$97.99

3 Year

$133.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Audio Implements Monitor Amplifier Specifications

  • Input

    600 ohms, female XLR-3 connector wet or dry input or telephone

  • Jack Input

    Separate RJ-11 Jack for telephone line input

  • Earphone Output

    8 ohms

  • Power Requirements

    9V alkaline battery
    Regulated external AC Adaptor

  • IFB Output

    1/4" (6.3mm) & 1/8" (3.5mm) jacks

  • Output

    2 Independent Channels

  • Power Output

    350mW each

  • Current

    Total quiescent current 10mA

  • Material

    Die cast aluminum body with black texture finish

  • Dimensions

    4-1/4 x 2-1/4 x 1-1/4" (10.8 x 5.7 x 3.2 cm)

  • UPC Code

    192223054967

1 Accessories for Audio Implements Model #655 Monitor Amplifier with Dialer and Microphone

  • All Accessories (1)
  • Cleaning Accessories (1)
Dekoni Audio Headphone Cleaning Wipes, 10 Pack
Dekoni Audio Headphone Cleaning Wipes, 10 Pack
$6.99

About Audio Implements Monitor Amplifier

The Model 655 Communications Amplifier operates similar to the model 650, but with more features. The dialer has the capability of storing 25 telephone numbers, a low battery light, built in microphone and defeatable ringer for incoming calls. To operate on the telephone line, use the RJ-11 or 3pin XLR jack on the box. The XLR-3 on this model is for all audio input, wet or dry . A 25' telephone cord is included (MAT-2 Part #341). Four thumb screws to remove battery.

This box has been updated to work on all types of phone lines.

Audio Implements Monitor Amplifier Features

  • Built in microphone and defeatable ringer for incoming calls
  • Separate RJ-11 Jack for telephone line input
  • Balanced input 600 ohms, female XLR-3 connector wet or dry input or telephone
  • Powered by 9V alkaline battery or regulated external AC Adaptor
  • Low Battery warning light
  • Diode protected circuit polarity
  • Thermally protected transformer
  • Total quiescent current 10mA
  • Adjustable gain control for the line output to max +2db
  • Die cast aluminum body with black texture finish
  • Key Pad with 25 number memory-30 digits each
  • Battery life has been improved

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience crystal-clear audio with this headphone amplifier's dual independent channels.
  • Connect seamlessly using the female XLR-3 connector for wet or dry input on this amplifier.
  • Monitor your audio with confidence, thanks to the 1/4" & 1/8" IFB outputs on this amplifier.
  • Enjoy versatile power options with a 9V battery or external AC adapter for this amplifier.
  • Rely on the durable die-cast aluminum build of this audio distribution amplifier for years.
  • Achieve optimal sound quality with the 8 ohms earphone output on this headphone amplifier.

What's in the box:

  • Audio Implements Model #655 Monitor Amplifier with Dialer and Microphone
  • Belt Clip
  • Audio Implements Warranty
