Antelope Audio MP32 32-channel Microphone Preamplifier, 32x Combo XLR/TRS Mic/Line Inputs

SKU: ANMP32

This item is no longer available.

Recommended Alternatives

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What is the purpose of the 32 class-A mic pres in the Antelope Audio MP32?

The 32 class-A mic pres in the Antelope Audio MP32 are designed to amplify the signal from your microphones, maintaining signal clarity and sonic realism throughout the recording process. They also come with phantom power, making them compatible with a wide range of microphones.

What are the benefits of the digital remote control feature in the MP32?

The digital remote control feature in the MP32 allows for easy remote management of the device's input types and mic gain levels. It's compatible with both Mac and Windows, providing fast setup and easy fine-tuning of individual mic preamp gain. This makes adjusting complex gain structure and preamp settings incredibly simple.

Can the Antelope Audio MP32 handle high-demand mics?

Yes, the Antelope Audio MP32 can handle high-demand mics. It offers excellent headroom and up to 68 dB of gain in 1 dB steps, making it capable of powering even the most demanding ribbon mics while maintaining ultra-low THD+N.

What are the XLR/TRS combo inputs on the Antelope Audio MP32?

The XLR/TRS combo inputs on the Antelope Audio MP32 are versatile inputs that allow you to connect a wide range of microphones and instruments to the device. Four of these inputs can function as Hi-Z instrument inputs, providing additional flexibility for your recording needs.

What is the purpose of the user-defined presets in the MP32's software control panel?

The user-defined presets in the MP32's software control panel allow you to save your preferred settings for gain structure and preamp settings. This makes it easy to recall your preferred settings with just a click, saving time and ensuring consistency across your recordings.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Antelope Audio MP32 Specifications

  • Analog Inputs

    32x Mic / Line on XLR Combos
    1-4 /32chx Line Di (HiZ) XLR Combos

  • XLR Combos: XLR

    +21 dBu Max Balanced

  • XLR Combos: 1/4" TRS Line / HiZ

    +45 dBu Max Balanced

  • Analog Outputs

    32x Lines on 4 x D-SUB 25, +27 dBu Max, 50Ohms

  • USB Input/Output

    Full-Speed; Data stream of 12 Mbit/s, control pannel only, Type B

  • Mic Preamp: Gain

    Programmable gain (Mic Pre/Line): +15 dB - 68 dB in 1dB steps
    Programmable gain (Line): +15 dB - 45 dB in 1dB steps

  • Mic Preamp: THD + N

    -110.5 dB

  • Power Supply

    Nominal 100-120 / 220-240 VAC, 50 or 60 Hz
    Actual 95-264 VAC, 50 or 60 Hz

  • Operating Temperature

    0 to 50deg. C / 32 to 122deg. F

  • Rack Unit

    2U

  • Dimensions (W x H x D)

    482 x 88 x 210mm / 18.98 x 3.46 x 8.27" (approx.)

  • Weight

    9lbs / 4.08kg (approx.)

  • UPC Code

    853744004274

About Antelope Audio MP32

Take your audio recording to the next level with the Antelope Audio MP32, a professional-grade 32-channel microphone preamplifier. This high-quality device is designed with an innovative approach to analog circuit design, ensuring exceptional clarity, transparency, and dynamic range in your audio output.

The MP32 is equipped with 32 class-A mic pres, complete with phantom power, and 32 line inputs, four of which can function as Hi-Z instrument inputs. All inputs are conveniently located on the front panel of the MP32, designed as versatile XLR combo inputs to accommodate a wide range of microphones and instruments.

Designed for consistent performance, the MP32's mic preamps deliver an open and transparent sound, maintaining signal clarity and sonic realism throughout the recording process. With excellent headroom and up to 68 dB of gain in 1 dB steps, this preamplifier can power even the most demanding ribbon mics while maintaining an ultra-low THD+N (-110.5 dB).

The MP32 is not just about superior sound quality; it also offers advanced control features. A user-friendly digital control panel, compatible with both Mac and Windows, allows for easy remote management of the device's input types and mic gain levels. This intuitive software control panel simplifies complex gain structure and preamp settings, providing fast setup and easy fine-tuning of individual mic preamp gain. It also allows for the independent assignment of phantom power and mic/line/hi-z switching.

User-defined presets are just a mouse click away, making it incredibly simple to recall your preferred settings. Additionally, the individual V/U style metering provides instant signal confirmation at a glance, making the MP32 a versatile and essential tool for any professional audio setting, be it recording studios or live sound applications.

Antelope Audio MP32 Features

  • 32-channel console-grade mic preamp with transparent, class-A circuitry
  • Dual-purpose XLR/TRS combo inputs for versatile microphone/instrument connectivity
  • Up to 68 dB of gain in precise 1 dB steps, ideal for a variety of mics
  • Digital remote control for easy management via Mac or Windows
  • Ultra-low total harmonic distortion plus noise (THD+N) for pristine audio quality
  • Intuitive software with user-defined presets and V/U style metering

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • 32-channel console-grade mic preamp with transparent, class-A circuitry
  • Dual-purpose XLR/TRS combo inputs for versatile microphone/instrument connectivity
  • Up to 68 dB of gain in precise 1 dB steps, ideal for a variety of mics
  • Digital remote control for easy management via Mac or Windows
  • Ultra-low total harmonic distortion plus noise (THD+N) for pristine audio quality
  • Intuitive software with user-defined presets and V/U style metering

What's in the box:

  • Antelope Audio MP32 32-channel Microphone Preamplifier
  • Owner's Manual
  • 4x 1.5' D-Sub Cable (DB25 Male
  • DB25 Male)
  • USB Cable
  • AC Power Cable
  • Antelope Audio 1 Year Limited Warranty
